JACTP ( Centrifugal Process )

JACTP ( Centrifugal Process ) Series solid injection moulded pumps are available in polypropylene (PP) and glass filled polypropylene (GFP) materials. These are suitable for all services compatible with PP. These Pumps incorporate robust design to handle highly corrosive fluids including corrosive slurries. ‘JACTP’ designed in accordance with DIN 24256 / ISO 2858, DIN 24255 Standards and in general confirming to API 610

Capacity - Q- up to : 3 400 M / hr
TDH- H- up to : 100 MLC
Temprature 80 C
Working Pressure : 6 Bars

  • Effluent Treatment
  • Filtration
  • Recirculation of Electrolytes
  • Alkalies Transfer
  • Chemical, Dyes & Intermediates
  • Effluent
  • Water Treatment Plant
  • Electro Plating
  • Descaling and Picking
  • Corrosive Gases like Cl2, F2, 802, 503, Co2, Nh3, etc.
  • Available in PP, GFP & PVDF
