JARP ENGINEERING JARP ENGINEERING company provides a Qualitative assortment or array of Industrial Process Pumps Casting, Industrial Valves Casting, Aerospace Casting, Turbine Blades Casting, Defense Casting, Power Plant Boiler Parts Casting, , Marine Applications Casting, Engineering & Automation Casting, Fire Fighting Equipment Casting, and Earth Moving Machinery Casting.We can produce or develop any piece as per your Drawing, Specification, or a Sample for 3D measurement.We ensure that each of our final products are tested thoroughly at various stages of production to meet stringent customer requirement such as Hardness, Tensile property, Impact, Casting Soundness (Dye Penetrate, Magnetic Particle, Radiography Test) etc.
Our Work
- Size per casting : 750X750X600mm
- Weight per casting : 25 grams to 125kgs
- Standards : Conforming to ASTM, DIN, AISI ,JIS, IS, BS, EN & other international standards
- Precipitation Hardened Stainless Steel
- Carbon Steel
- Ferritic Stainless Steel
- Duplex Stainless Steel
- Martensitic Stainless Steel
- Cobalt Base Alloys
- Austenitic Stainless Steel
- Nickel Base Super Alloys
- Non Metallic Materials such as PP, PVDF, PFA, FEP etc
- Tolerance on Angle : + 10
- Configuration like, small hole, Blind hole, Slot, Groove, Serration, Knurling, Under-cuts can be achived as cast, depending upon overall geometry, complexity and size of the components.
- Surface Roughness : As Cast : 3.0 to 6.0 Ra µ
- Machining Allowances : 0.5mm to 2mm wherever machining fitment is expected
- More closer dimensional tolerance also can be achived , as per International standard ,with additional operations.
Work
| Nominal Dimension(mm) | Overall Dimension(mm) | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| Over | Up to | Up to 6 | 6 to 10 | 10 to 18 | 18 to 13 | 30 to 80 | 80 to 180 | 180 to 300 | 300 to 500 |
| 0 | 6 | ± 0.10 | ± 0.12 | ± 0.15 | ± 0.20 | ± 0.25 | ± 0.25 | ± 0.30 | ± 0.35 |
| 6 | 10 | ± 0.12 | ± 0.15 | ± 0.25 | ± 0.25 | ± 0.30 | ± 0.35 | ± 0.45 | |
| 10 | 18 | ± 0.20 | ± 0.30 | ± 0.35 | ± 0.35 | ± 0.40 | ± 0.55 | ||
| 18 | 30 | ± 0.30 | ± 0.40 | ± 0.45 | ± 0.50 | ± 0.65 | |||
| 30 | 80 | ± 0.45 | ± 0.55 | ± 0.60 | ± 0.75 | ||||
| 80 | 180 | ± 0.60 | ± 0.70 | ± 0.90 | |||||
| 180 | 300 | ± 1.00 | ± 1.15 | ||||||
| 300 | 500 | ± 2.00 | |||||||
